Products Description

Type

SP(Integrated Low Pressure System)







Inner Tank Material

Food grade SUS304 2B or SUS316L







Inner Tank Diameter

Φ360mm;Φ370mm;Φ380mm;Φ420mm







Inner Tank Thickness

0.31mm;0.38mm;0.4mm







Outer Tank Material

SPCC;PVDF;SUS304;SUS316;Colorful plate







Outer Tank Diameter

Φ460mm;Φ470mm;Φ480mm;Φ520mm







Inner Tank Thickness

0.4mm 0.45mm 0.5mm







Tube Material

3-target all glass tube  ( High quality borosilicate glass )







Vacuum Tube Size(mm)

58/1800 (diameter/length)







Tube Number

9/10/12/15/18/20/24/30/32/36/40







Frames (Stand Parts)

Galvanized plate, Stainless steel or Aluminum alloy







Insulation Layer

High quality polyurethane foam made by advanced high pressure foam machine







Insulation Thickness

50mm,55mm,60mm







Hail Resistance

25mm







Operation Pressure

0.05Mpa







Details Images



Product packaging
