2.5 KVA 24V Felicity Solar INVERTER

122,000.00

In stock

1. Built-in AC charger and MPPT solar charge controller( optional ).

2. Build-in battery reverse polarity protection.

3. Adjustable charge current and output frequency.

4. RS-232 communication interface.

5. The generator has the function of automatic control on and off.

6. Full function LCD and LED display.

7. AC input and output protection switch.

8. Build-in battery temperature compensation interface.

9. Automatic AC and PV charger after shutdown.

10.Low frequency high reliable pure sine wave circuit architecture.

11. Optional 8 types of batteries, three-stage intelligent charger.

Compare
Categories: ,

Solar inverter, or converter, or PV inverter converts the variable DC output of a photovoltaic (PV) solar panel into a utility frequency alternating current (AC) that can be off-grid electrical network. It is a critical balance of system–component in a solar power system, allowing the use of ordinary AC-powered equipment.

1kw solar grid tie inverter



Solar inverter, or converter, or PV inverter converts the variable DC output of a photovoltaic (PV) solar panel into a utility frequency alternating current (AC) that can be off-grid electrical network. It is a critical balance of system–component in a solar power system, allowing the use of ordinary AC-powered equipment.





1kw solar grid tie inverter

  Line Mode Specification
   Model FL-IVP1512-1500VA FL-IVP3524-3500VA FL-IVP5048-5000VA FL-IVP7548-7500VA FL-IVP10048-10000VA
   Input Voltage Waveform Pure Sine Wave (Utility or Generator)
   Nominal Input Voltage 110V-120V / 220V- 240V
   Max AC Input Voltage 140V / 270V
   Nominal Input Frequency 50Hz / 60Hz (Auto detection)
   Output Voltage Waveform As same as input waveform





Inverter Mode Specification
Model FL-IVP1512-1500VA FL-IVP3524-3500VA FL-IVP5048-5000VA FL-IVP7548-7500VA FL-IVP10048-10000VA
Output Voltage Waveform Pure Sine Wave
Rated Output Power 1500VA 3500VA 5000VA 7500VA 10000VA
Nominal Output Voltage 110V-120V / 220V- 240V ± 10%
Nominal Output Frequency 50Hz / 60Hz ±0.3Hz
Nominal Efficience 80%
Capable of starting electric motor 1HP 2HP 3HP
Nominal DC Input Voltage 12V 24V 48V



Charge Mode Specification
Model FL-IVP1512-1500VA FL-IVP3524-3500VA FL-IVP5048-5000VA FL-IVP7548-7500VA FL-IVP10048-10000VA
MAX Charge Current 35A 30A 40A 50A
Charge Current Regulation Charge current adjustable: 25%, 50%, 75%, 100%(Optional)
Battery Type Selection Select the right type of battery to charge (e.g: GEL, AGM, Open lead acid, Sealed lead acid, etc )
Charge Algorithm Three stage: Boost CC (constant current stage)—Boost CV (constant voltage stage)—Float(contact voltage stage)



Product Feature

1kw solar grid tie inverter

Features:

1. Build in AC charger and MPPT solar charge controller( optional ).

2. Build in battery rever se polarity protection.

3. Adjustable charge current and output frequency.

4. RS-232 communication interface.

5. Generator has function of automatic control on and off.

6. Full function LCD and LED display.

7. AC input and output protection switch.

8. Build in battery temperature compensation interface.

9. Automatic AC and PV charger after shutdown.

10.Low frequency high reliable pure sine wave circuit architecture.

11. Optional 8 types of batteries, three-stage inteligent charger.
