New Arrival jsdsolar 4KW 5.5KW Hybrid Solar Inverter Off Grid Pure Sine Wave Wifi Inverter 24V 48V 230V Output with MPPT 100A Solar Charger CAN RS485
Product Features
1.Pure sine wave inverter
2.Configurable input voltage range for home appliances and personal computers via LCD setting
3.Configurable battery charging current based on applications via LCD setting
4.Configurable AC/Solar Charger priority via LCD setting
5.Compatible to mains voltage or generator power
6.Auto restart while AC is recovering
7.Overload/Over temperature/short circuit protection
8.Smart battery charger design for optimized battery performance
9.Cold start function
INVERTER MODEL
J4000HC
J5500HPC
Parallel Capability
No
Yes,9units
Line Mode Specifications
Nominal Input Voltage
230Vac
Max AC Input Voltage
280Vac
Efficiency(Line Mode)
>95%( Rated R load,battery full charged)
Transfer Time
10ms typical(UPS);20ms typical(Appliances)
Inverter Mode Specifications
Rated Output Power
4KW
5.5KW
Output Voltage Waveform
Pure Sine Wave
Output Voltage Regulation
230Vac±5%
Output Frequency
50/60Hz
Peak Efficiency
93%
Overload Protection
3s@≥150% load;5s@101%~150% load
Nominal DC Input Voltage
24VDC
48VDC
Floating Charge Voltage
27VDC
54VDC
No Load Power Consumption
30W
50W
Charge Mode Specifications
AC Charging Current (Max)
100A
100A
Max. PV Array Power
5000W
5500W
PV Array MPPT Voltage Range
40Vdc~450Vdc
120Vdc~500Vdc
Max. PV Array Open Circuit Voltage
500Vdc
Grid-Tie Operation
Nominal Output Voltage
220/230/240VAC
Feed-in Grid Voltage Range
195-253VAC
Feed-in Grid Frequency Range
49-51±1Hz/59-61±1Hz
Nominal Output Current
18A
26A
Maximum Conversion Efficiency(DC/AC)
97%
Battery and Communication
Battery Type
LiFePO4/ Lithium/ Lead-acid/ User-define
Embedded Interfaces
RS485/ CAN/ USB/ Dry contact
External Modules
WIFI
Main Load Cut Off Voltage
-10～60℃
Cooling Method
Intelligent Fan
