APC Smart-UPS SRT 6000VA 230V – SRT6KXLI

1,204,500.00

Categories: ,

Specification:

  • Output Power Capacity: 2700 Watts / 3000 VA
  • Max Configurable Power: 2700 Watts / 3000 VA
  • Nominal Output Voltage: 230V
  • Output Voltage Note: Configurable for 220 : 230 or 240 nominal output voltage
  • Efficiency at Full Load: 95.0%
  • Output Voltage Distortion: Less than 5% at full load
  • Output Frequency (sync to mains): 47 – 53 Hz for 50 Hz nominal, 57 – 63 Hz for 60 Hz nominal
  • Topology: Line Interactive
  • Waveform Type: Sine wave
  • Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
  • Typical recharge time: 3 hour(s)
  • Replacement Battery: RBC55

APC Smart-UPS SRT is a family of high-density, performance UPSs for voice and data networks, medical labs, and light industrial applications. Capable of supporting 10kVA in a 6U rack/tower convertible form, users can support power hungry blade servers or heavily loaded equipment racks. This flexible form factor allows standardization across multiple applications. High power internal chargers allow virtually unlimited additional matching battery packs to comply with aggressive runtime demands of business-critical systems. Customers with harsh power environments looking for extremely tight voltage and frequency regulation, internal bypass, and input power factor correction typical of double conversion online topology will get them in the Smart-UPS RT.

Specification:

  • Max Configurable Power: 6000 Watts / 6000 VA
  • Nominal Output Voltage: 230V
  • Output Voltage Distortion: Less than 2%
  • Output Frequency (sync to mains): 50/60Hz +/- 3 Hz
  • Other Output Voltages: 220, 240
  • Crest Factor: 3 : 1
  • Topology: Double Conversion Online
  • Waveform Type: Sine wave
  • Nominal Input Voltage: 230V
  • Input Frequency:  40 – 70 Hz (auto sensing)
  • Input Connections: Hard Wire 3 wire (1PH+N+G)
  • Input voltage range for main operations: 160 – 275V
  • Control panel: Multi-function LCD status and control console
  • Audible Alarm: Audible and visible alarms prioritized by severity
  • Emergency Power Off (EPO): Yes
