Description:
1.Compact structure, high-lift, noiseless, pollution-free.
2.Complete electrical protecting controller device, against
under-voltage, over-voltage, over-flow,overload,
waterless etc.
3. Dry-run protection: Automaticly restart in 15-30
minutes.
4. AC/DC autoswitch: DC priority.
Specification:
Model: 4JC22/62-D216/2200
Power: 2200W / 3HP
Max Flow: 5811GPH / 22,000L/H
Max.Head: 203FT / 62m
Outlet: 2″
Pump Dia.: 4″
Cable: 2m
Max. DC Open circuit voltage:420V
AC input voltage: 80V-240V
Max. Temperature of Water Handled: 35°C
Controller Feature:
1. AC/DC autoswitch: DC priority, AC power input if DC was
not enough.
2. Waterproof grade: IP65,
3. Soft start technology: No impulse current to protect the motor.
4. Under-voltage protection; Over-voltage protection;
Over-flow protection; Overload protection;
waterless protection; High temperature protection.
Package Include:
– 1 x 4″ Solar pump with 2m cable
– 1 x AC/DC Pump controller
– 1 x Water level sensor
– 1 x Splice kit for cable join
– 1 x Splice kit for waterproof
Package DO NOT Include:
– Solar panels.
Application:
Irrigation, high efficiency of increasing oxygen on aquaculture,
pumping water from deep well, gardening, fountain and etc.
